CNC High-Speed Engraving & Milling Machine — key technical parameters. Sharpens the cutting knife edge after etching — Japanese THK rails, 24 000 rpm spindle, 16-tool magazine.
Model: GE760_A16S
Sharpens the cutting knife edge after etching — Japanese THK rails, 24 000 rpm spindle, 16-tool magazine.
Request a quote| Stroke | 700 × 600 × 350 mm (XYZ) |
|---|---|
| Table size | 720 × 650 mm, load 500 kg |
| Spindle | Φ125, 24 000 rpm electric |
| Tool magazine | 16 |
| Positioning | 0.01 / 0.01 / 0.008 mm |
| Power / weight | 380 V / 50 Hz / 6200 kg |
This is a parameter-overview page. A more detailed product page with full specifications, optional configurations, and process recommendations is being prepared. In the meantime, please contact our engineers for the full datasheet and quote.
For photo-engraving workflows, the chemical pattern-transfer path uses a PCB developing machine (sodium carbonate developer) before the acid etch — same chemistry and same equipment as PCB fabrication, with the GE-D650W handling stainless steel, brass, copper and aluminum plates up to 650 mm wide.
