Etchant Regenration system


etchant Regenration system
automatic dosing system for chemical etching

Features:The Regenration system is suitable for the regeneration of circuit board / metal acid etching solution.This control system uses ORP and conductivity meter,digital display, interactive, many kinds of parameters setting and operation method. Safety and stability.
1.Humanized 10-inch human-machine operation interface, Chinese and English operation interfaces can be switched selectively, parameter setting is simple, easy to understand and operate;
2.PLC fully intelligent control host with communication function, data storage function, automatic temperature compensation function and report statistics function;
3. High-performance detection sensor, internal high-speed signal processing system, accurate and stable control accuracy;
4. This system can adapt to various harsh environments and can be used for precise control and addition of a variety of redox chemicals.
control target:
1. Oxidant control potion ORP value
2. Hydrochloric acid controls the acidity value of the potion
3. Specific gravity control potion specific gravity value
4. Temperature monitoring potion temperature value

Contact Us Regarding Product

Main technical parameter:
Measurement specifications: Copper concentration: 0.01~5.5g/L
Copper etching concentration: 0.01~50g/L Resolution: 0.01g/L
Technical specifications: Monitor and control the proportion of liquid, used for all kinds of industrial control.
It is used for ferric Chloride, copper chloride and Tin-lead Stripping PCB etching.
Liquid proportion control in industrial process, such as brine mixing.
It can converter every chemical concentration, such as PPM,%,Baume.
Large storage batter eletrolyte concentration monitoring.
Size: 1200*1200mm
Measure scope: A: 1.000-1.200 B: 1.150-1.350 C: 1.300-1.500
Accuracy: ±0.003 SG
Resolution: ±1 Digit
Display : 3 1/2 ,LED
Action control:HI/LO (2 points contactor )
Set points : 2
Junction Currency: 110VAC M.5A/240VAC M.3A
Power supply:110/240VAC,50/60Hz±15%
